The TS3 is a coalescer-separator designed to remove tramp
oils from metalworking fluids and wash-water. We build our
systems with larger separation tanks and more coalescing
media than the competition. This ensures COMO can
remove tramp oil, prevent microbial growth, and extend fluid
life in the most difficult applications.
Turnkey Filter Cart
This Product Recycles
- Coolant
- Cutting fluid
- Grinding fluid
- Stamping fluid
- Parts washer fluid
- Polymer quenchant
- Many other industrial fluids
Specifications
- 3 GPM, 1/2″ air diaphragm pump with poly body
- Portable, powder-coated steel tank
- 50 gallon separation-tank with PVC coalescing media
- Clean fluid discharge height of 37″
- Temperature rating of 140°F (60°C)
- Dimensions: 32′ W x 24″ D x 64″ H
- Approximate weight: 265 lbs.
Standard Features
- Air filter & regulator to control inlet air pressure
- Needle valve to adjust pump cycle-speed and fluid flow rate
- Adjustable oil-gate for tramp oil removal
- COMO Dual Weir floating pickup
- Hanging inlet bag-filter
- 5″ heavy duty wheels
- Inlet tee strainer to protect pump
Don’t let tramp oils & microbes destroy your fluid and stink-up your shop.
Extend fluid life and improve part quality by using a COMO TS3.
Request a quote today!
Complete the form below to get in touch with COMO Filtration Systems about the Model TS3 Coalescer-Separator.
